Converting to Hyper 35

The world's first 35mm ENG Camera in 25i/p & 30p (soon in 24p & 25p)

The Hyper 35 promotional video: http://www.youtube.com/watch?v=L5iEA_TdkOc

The Hyper 35 ENG camera is a Hybrid of the Canon 5DMKII adapted to the versatility of a Sony Betacam body with video monitoring, viewfinder and sound recording features.

Electricfilms are offering conversions for your Sony camcorder and have several cameras in stock ready for conversion.


35mm stills camera used in photo

The Hyper 35 Conversion details

The Canon 5DMKII attaches to a custom made bracket and is quick released attached to the front of a Sony camcorder. (not show in previous photos or videos) You then plug in the 5D and you are shooting. The 5D can be quick released from the cradle easily and the leads into the camera body are protected by a custom made frame.

All camera controls are accessible. The electronic 1.5" B&W viewfinder is easy to focus thanks to the electronic peaking circuits which is a bonus with the shallow depth of field of 35mm. The Hyper 35 ENG camera is lightweight and balances nicely on the shoulder or tripod.

Monitoring

The Director's monitor can also be installed on the operator's side if going without the audio recorder. We also supply a very high quality Marshal LCD outdoor monitor.

Sound

The integrated Beachtec pre-amp sends a 15kz tone into channel 1 (filter out in post) which steadies the auto gain in the Canon for this channel as well as channel 2.

Monitoring

Go without leads with the 5.8ghz SD transmitter or plug in a HDMI or video lead into the Hyper 3. We also have a good value 24" HDMI/SD monitor enclosed in a carry frame that also attaches to a light stand.

Power

Go with the original NP1 batteries or have a V lock installed.

Conversion Cost

International Customers: USD
Australian residents: AUD plus GST

Initial Hyper 35 Conversion - $1750
The Canon 5DMKII attaches to a quick release to the front of a Sony Camcorder with internal power supplies, video distribution amps, 12V power in, HDMI and Video out. Ship your own Camcorder for conversion or check our stock for availability.

Integrated Director/Client monitor - $850


Integrated Beachtec pre-amp - $1250

Integrated SD video transmitter and mini monitor - $850

Canon's 'out of shot' preview area output

V lock battery plate integrated with Hyper 35 - $375

Hyper 35 Accessories

Very high quality outdoor 6.5" Marshall LCD monitor (Monitor details) - $1850
Integrated into operator side of Hyper 35 - $750



Marantz flash recorder $675
(2 track 3 pin 48v XLR in, 48k & 96k Wav or MP3 recording with meters)
With V lock & internal power supply - $375
Integrated into Hyper 35 - $950

Dell 24" HDMI & SD field Monitor in carry frame - $1450

Power tap & dummy Canon battery - $375

12v power tap for Radio Microphone - $250

Additional Quick release plates - $160
(For attaching Canon 5DMKII from Hyper 35 direct to a tripod)

Additional Canon 5DMKII mount - $260
Custom designed to snugly fit a Canon 5DMKII camera body.
Machined from a single piece of aluminum, it provides full access to all switches,
battery drawer and protects the plugs coming into the camera.
(The mount is already supplied with the Hyper 35)

Sennheiser M66 microphone kit - $1450


(Recommended camera microphone for the Hyper 35 if using the
Beachtec pre-amp system.)

The Hyper 35 Conversion

Stills camera, NP1 Battery & radio transmitter shown in photo

The Hyper 35 now has the camera mounted upright with a quick release and molded camera cradle.
When you release the 5D it has a loupe with rubber shroud eye viewfinder.
